DRONES - GLOBAL GOLD & OIL

---

Our aerial systems are supported by a comprehensive approach that includes design engineering, maintenance readiness, and mission support planning.

These platforms are developed with repairability, supportability, and sustained operational use in mind.

• UAS DESIGN AND ENGINEERING

Our platforms can be configured for different levels of operational demand and mission-specific requirements. Their modular architecture supports adaptation across multiple environments and applications.

• MAINTENANCE AND SUSTAINMENT

The support approach includes replaceable components, maintenance readiness, and logistics continuity to help preserve operational availability.

• TRAINING SUPPORT

Where required, operator familiarization and training support can be coordinated to strengthen team readiness and help maximize platform use.

 DRONE MODEL: PERSES FPV QUAD

A lightweight FPV multirotor platform designed for versatility, efficiency, and rapid deployment. It is intended for operators who require a modular and adaptable solution with multiple size and payload configurations.

SPECIFICATIONS

• Modular / serviceable system

• Multiple payload options available

• Picatinny rail payload mount

• Ultra-lightweight / all carbon fiber

• Foldable, waterproof

• Ready to fly in less than 1 minute

• Low acoustic signature

• Models and payloads:

  • 3" — 600 g

  • 5" — 900 g

  • 8" — 2.0 kg

  • 10" — 4.0 kg

  • 10" HL — 5.5 kg

  • 13" — 6.0 kg

 DRONE MODEL:  MATRIX 5 / MATRIX 10 / MATRIX 15

A family of lightweight tactical UAVs developed to provide versatility, speed, and adaptability across different operational scenarios. Available in multiple sizes and configurations.

SPECIFICATIONS

• Battle tested and developed

• Ready to fly in less than 1 minute

• Payload agnostic up to 7 kg

• Various C2 options

• HUSH encryption

• Compatible digital radios

• Analog and digital VTX support

• Dual camera switcher included and ready to plug in

• Various EO camera options

• Various thermal camera options

• Click-on side covers to protect electronics

• Universal payload mount included

• Fiber optic ready

• Maritime ready

 DRONE MODEL:  MRK1-8

An 8-inch FPV platform designed for operational flexibility, quick assembly, and compatibility with variable payloads in demanding scenarios.

SPECIFICATIONS

• Quick operator assembly / disassembly

• Prop disc separated to clear larger payloads up to 3 kg

• Three 30x30 stack mounts for companion computer and digital VTX

• Lightweight camera suitable for night operations

• Motors 2814, 880KV

• Electronics conformally coated for wet-weather operation

• Estimated range:

  • 30 km without payload, LOS


  • 22 km with 1.5 kg payload, LOS


  • 15 km with 3 kg payload, LOS

DRONE MODEL:  HALO X4

A lightweight medium-sized modular quadcopter with configurable payload architecture and a professional mission-oriented design for agile and adaptable operations.

SPECIFICATIONS

• Max flight time: 2 hours

• Max payload: 7 kg

• Ultra lightweight / all carbon fiber

• Foldable, waterproof

• Low acoustic signature

• Reconfigurable payloads:

  • EO / IR thermal cameras

  • Night vision

  • LiDAR / mapping

  • Ground penetrating radar

  • Single and multiple dropper

  • Megaphone

• C2 and encryption options

• Digital radio ready

• Winch

• Repeaters / mesh

• Fiber optics / mothership

•  IRONGHOST REPEATER

A fully integrated repeater with telemetry and video link, compatible with IRONghost ground and air systems, designed to extend operational range and enable beyond-line-of-sight missions.

SPECIFICATIONS

• Power requirements: 2s–6s (7V–28V)

• XT30 connector

• Total weight: 350 g with antennas

• Two control / telemetry radios

• 3W RF output power for control link

• EW-resilient IRONghost protocol

• Wide-band frequency range video link

• Hybrid sub-GHz ground link

• 25mW - 1.5W video downlink

• GROUND CONTROL SYSTEM

A complete tactical FPV operations system designed for safe and reliable field deployment.

SPECIFICATIONS

• Tac.Ctrl tactical remote controller

• IRONghost C2 radio

• IRONghost 5.8 GHz video link

• FPV / Pro goggles

• Tripod, cables, and tactical case

• Radio modules may be displaced up to 1 km from the pilot for survivability

Beyond the aerial platforms themselves, GLOBAL GOLD & OIL can facilitate complementary support solutions according to client requirements, mission profile, and long-term operational planning.

These resources are intended to reinforce platform continuity, field readiness, and implementation support when a project requires a broader operational scope.

• SPARE PARTS AVAILABILITY

For clients seeking greater maintenance continuity and readiness, access to essential spare parts may be coordinated according to the platform and deployment profile.

• PROP. (PROPELLERS / BLADES)

• BATT. (SMART BATTERIES)

• MOT. (BRUSHLESS MOTORS)

• ESC (ELECTRONIC SPEED CONTROLLER)

• FC (FLIGHT CONTROLLER)

• GIMB. (GIMBAL / STABILIZER)

• STRUCT. (FRAME)

• VTX (VIDEO TRANSMITTER)

• LAND. GEAR (LANDING GEAR)

• RC (RADIO CONTROL)

• FPV GOGGLES


Leading brands such as DJI offer model-specific spare parts for platforms such as Mavic, Phantom, Mini, Avata, and Agras, typically available as repair kits or replacement parts.

• TRAINING SUPPORT

For organizations requiring broader operational adoption, training and implementation support may also be considered as part of the overall solution.

• INSURANCE

Comprehensive insurance options may also be explored to help protect equipment, operations, and assets against unforeseen events, reinforcing long-term continuity and project stability.

 Our aerial solutions may be configured with a broad range of sensors according to mission profile and operational objective.

SENSOR CATEGORIES

• Electro-optical sensors

• Infrared / thermal sensors

• Multispectral and hyperspectral sensors

• LiDAR

• Radar

• GNSS and inertial sensors

• Environmental and atmospheric sensors

• Acoustic and vibration sensors

• Electronic and signal sensors

• Specialized and emerging sensors


APPLICATIONS

• Surveillance and observation

• Mapping and inspection

• Search and rescue

• Target recognition and tracking

• Environmental monitoring

• Infrastructure assessment

• Border and perimeter security

• Tactical operational intelligence
